MyBatis Generator is a code generation tool officially provided by MyBatis, which can help developers quickly generate Java Beans, Mapper interfaces and XML mapping files that conform to the database table structure. In the process of using MyBatis Generator for code generation, the setting of configuration parameters is crucial. This article will delve into the best practices of MyBatis Generator from the perspective of configuration parameters and provide readers with specific code examples.

1. Configuration file description

Before using MyBatis Generator for code generation, you need to write a configuration file named generatorConfig.xml to guide the generation of code. Behavior. The following is a simple configuration file example:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE generatorConfiguration PUBLIC
        "-//mybatis.org//DTD MyBatis Generator Configuration 1.0//EN"
        "http://mybatis.org/dtd/mybatis-generator-config_1_0.dtd">
<generatorConfiguration>
    <context id="DB2Tables" targetRuntime="MyBatis3">
        <!-- 數據庫連接信息 -->
        <jdbcConnection driverClass="com.mysql.cj.jdbc.Driver"
                        connectionURL="jdbc:mysql://localhost:3306/test"
                        userId="root"
                        password="123456">
        </jdbcConnection>

        <!-- 實體類、Mapper接口、XML映射文件生成路徑 -->
        <javaModelGenerator targetPackage="com.example.model"
                            targetProject="src/main/java">
        </javaModelGenerator>

        <sqlMapGenerator targetPackage="mapper"
                         targetProject="src/main/resources">
        </sqlMapGenerator>

 ? ? ? ?<!-- Mapper接口的生成 -->
 ? ? ? ?<javaClientGenerator type="XMLMAPPER"
                              targetPackage="com.example.mapper"
                              targetProject="src/main/java">
 ? ? ? ?</javaClientGenerator>

 ? ? ? ?<!-- 數據庫表及生成的代碼配置 -->
 ? ? ? ?<table tableName="user" domainObjectName="User"
               enableCountByExample="false"
               enableUpdateByExample="false"
               enableDeleteByExample="false"
               enableSelectByExample="false"
               selectByExampleQueryId="false">
 ? ? ? ?</table>
    </context>
</generatorConfiguration>

In the above configuration file, we define the database connection information, generated entity class, Mapper interface and XML mapping file path, and set the database table to generate code and related configurations.

2. Configuration parameter analysis

In the configuration file, there are some key configuration parameters that require our special attention. They play a decisive role in the effect and quality of the generated code. Let’s parse these parameters one by one:

(1)jdbcConnection

jdbcConnection node is used to configure database connection information, including database driver class, connection URL, username and password, etc. In actual applications, you need to make corresponding modifications according to your own database configuration.

(2)javaModelGenerator

javaModelGenerator The node is used to configure the package name and storage path of the generated entity class (Java Bean). By setting the targetPackage and targetProject parameters, we can specify the generation path of the entity class.

(3)sqlMapGenerator

sqlMapGenerator node is used to configure the package name and storage path of the generated XML mapping file. Similarly, we can specify the generation path of the XML mapping file by setting the targetPackage and targetProject parameters.

(4)javaClientGenerator

javaClientGenerator node is used to configure the package name and storage path of the generated Mapper interface. By setting the type parameter to XMLMAPPER, you can specify to generate a Mapper interface based on XML configuration.

(5)table

table The node is used to configure the database table information for generating code, including table name, generated entity class name, Whether to enable specific query methods, etc. You can control the behavior of generated code by setting different properties.

3. Best Practices

When using MyBatis Generator to generate code, we can follow the following best practices:

(1) Keep the configuration file concise and clear

Try to avoid adding too many configurations to the configuration file, and you can flexibly adjust the scope and content of the generated code according to project needs. At the same time, configuration files with clear comments and simple structure help code maintenance and management.

(2) Select the generated object according to actual needs

In the table node, you can choose whether to enable certain query methods according to specific needs to reduce the redundancy of generation code. For example, if you do not need to use the selectByExample method, you can disable it by setting enableSelectByExample="false".

(3) Add custom plug-in

In addition to the default generation rules, we can also write custom plug-ins to extend the functionality of MyBatis Generator. By writing plug-ins, you can achieve a more flexible code generation strategy that better meets project needs.

4. Code example

The following is a complete example showing how to use MyBatis Generator to generate a simple User entity class and the corresponding Mapper interface and XML mapping file:

public class User {
    private Long id;
    private String username;
    private String password;

    // Getters and setters
}

public interface UserMapper {
    int insert(User record);

    int deleteByPrimaryKey(Long id);

    int updateByPrimaryKey(User record);

    User selectByPrimaryKey(Long id);
}

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.example.mapper.UserMapper">

    <resultMap id="BaseResultMap" type="User">
        <id column="id" property="id" />
        <result column="username" property="username" />
        <result column="password" property="password" />
    </resultMap>

    <insert id="insert" parameterType="User">
        INSERT INTO user (id, username, password) VALUES (#{id}, #{username}, #{password})
    </insert>

    <!-- 其他SQL語句 -->

</mapper>

Conclusion

Through the introduction of this article, readers should have a deeper understanding of the configuration parameters of MyBatis Generator and understand the best practices. In actual projects, by setting configuration parameters appropriately and using custom plug-ins flexibly, the MyBatis Generator tool can be used more efficiently to generate code that meets project requirements. I hope this article will be helpful to readers when using MyBatis Generator.
