CSS Grid is a tool for two-dimensional layout of web pages. After creating a container with display: grid, use grid-template-columns and grid-template-rows to define rows and columns; 1. Use fr units or fixed values ??to set the size; 2. Use gap to control spacing, justify-items and align-items to control alignment; 3. Specify the starting line position of the child item through grid-column and grid-row; 4. Use repeat() to simplify repeated structure definitions; 5. Use grid-area to implement named area template layout.

CSS Grid is a powerful tool for modern web layout, especially suitable for two-dimensional grid structures. It is not only good at single-directional arrangement like Flexbox, but it can handle rows and columns at the same time, giving you more flexibility in controlling page structure.

Basic syntax: define a grid container

To use CSS Grid, you must first set display: grid; on the container. This step is the basis. If this attribute is not added, the subsequent grid settings will not work.

Then you can use grid-template-columns and grid-template-rows to define the number and size of columns and rows. for example:

 .container {
  display: grid;
  grid-template-columns: 1fr 2fr 1fr;
}

The above code will create three columns, the middle column is twice as wide as the left and right columns. The fr unit is a feature of Grid, indicating "the proportion of available space".

You can also use a mix of fixed values ??(such as 200px ) and proportional units:

 grid-template-columns: 200px 1fr 2fr;

Control spacing and alignment

The gap between grids can be set using the gap attribute, which can set the spacing between rows and columns at the same time, such as:

 gap: 20px 30px;

Equivalent to:

 row-gap: 20px;
column-gap: 30px;

In terms of alignment, Grid provides justify-items and align-items to control the alignment of child elements within cells. For example:

• justify-items: center; let all children center horizontally
• align-items: start; let them align the top

If you just want to control the location of a child separately, you can use justify-self or align-self .

Use grid-line to name or number content

You can precisely control the position of the child by specifying which line it starts from and which line it ends. for example:

 .item {
  grid-column: 2 / 4;
  grid-row: 1 / 2;
}

The meaning of this code is: this element starts from the second vertical line and spans to the fourth line; it is displayed on the first line.

You can also name these lines, which makes it more intuitive to write:

 grid-template-columns: [col1-start] 1fr [col2-start] 1fr [col2-end];

Then when positioning, you can write it like this:

 grid-column: col1-start / col2-end;

Several Tips to Simplify Complex Layouts

• Use repeat() to simplify the repeat structure
  If there are multiple columns of the same width, you do not need to write them one by one:

   grid-template-columns: repeat(3, 1fr);

• Automatically adjust the number of columns and adapt to container width

   grid-template-columns: repeat(auto-fit, minmax(200px, 1fr));

  This combination is very practical and is especially suitable for responsive designs.

• Quickly layout templates with grid-area You can directly name each region and define the template structure in the container:

   .container {
    display: grid;
    grid-template-areas:
      "header header"
      "sidebar main"
      "footer footer";
  }

  Then, just add the corresponding grid-area: header; for each child to automatically return.

  ---

  Basically, that’s all. By mastering these basic concepts and common techniques, you can easily make various complex grid layouts.
