How to convert AutoCAD DWG to PDF?

Jul 07, 2025 am 01:04 AM

To convert AutoCAD's DWG file into PDF, 1. You can use the export function that comes with AutoCAD: click "Application Menu" → "Output" → "Print", select "DWG To PDF.pc3" virtual printer, set paper, layout and other parameters before saving; 2. You can also enter PLOT through the command line to quickly operate and enable background processing; 3. If batch conversion is required, you can use the built-in or third-party batch printing tool to add multiple files and set the output path to export in one click; precautions include: Ensure that the scale and line scale settings are correct, adjust the background color, and select high-resolution configuration files to avoid blurred content or abnormal display. It is recommended to test the export effect in advance to ensure delivery quality.

How to convert AutoCAD DWG to PDF?

It is actually quite common to convert AutoCAD DWG files into PDFs, especially when you need to share drawings with people who do not have CAD software installed. The method is not difficult, but there are several details that are prone to errors. Let’s talk about how to operate and what needs to be paid attention to.

How to convert AutoCAD DWG to PDF?

Directly export PDF with AutoCAD functions

AutoCAD has built-in function to export PDFs since earlier versions, and the operation is the most direct:

How to convert AutoCAD DWG to PDF?
  • After opening the DWG file, click on the "Application Menu" in the upper left corner (that is the A icon)
  • Select "Output" > "Print" or press Ctrl P directly
  • In the printing interface, change the "Printer/Plotter" item to "DWG To PDF.pc3" or a virtual printer with similar name
  • Set the paper size, direction, layout and other contents
  • Click "OK", then select the save location and file name

This method is suitable for exporting a single drawing, but if there are multiple layout pages in a DWG, you need to switch one by one before exporting.


Use the Publish as PDF shortcut

If you are used to using the command line or want to operate faster, you can try the following method:

How to convert AutoCAD DWG to PDF?
  • Enter PLOT on the command line and enter
  • Also select "DWG To PDF.pc3" as the printer
  • Set page parameters, such as proportion, range, background color, etc.
  • Checking "Background Processing" allows you to continue operating the software without getting stuck

This method is essentially the same as above, but it is more closely related to the operating habits of old users.


Export multiple DWG files in batches as PDF

If there are a bunch of DWG files that need to be converted into PDF at one time, it will take too time to export them manually one by one. At this time, you can use AutoCAD's "Batch Plot" or use a third-party plug-in:

  1. Install the "Batch Plot" plugin (many CAD versions come with their own)
  2. Add multiple DWG files after opening the plugin
  3. Set unified printing options and output paths
  4. Export all files as PDF in one click

This method is particularly suitable for the final stage of the project and is used when sorting out and delivering materials.


Note: Are the contents blurred or missing after the PDF is opened?

Sometimes the exported PDFs have poor display effects, which may be due to the following reasons:

  • The scale setting is incorrect. It is recommended to select "Fill the drawings" or customize the fixed ratio, such as 1:100
  • Linear zoom is not checked, it is best to check the "Scaling Linear" item.
  • If the background of the drawing is black, remember to change the "background color" to white in the page settings before exporting, otherwise the PDF will feel uncomfortable if it is black on the white background and white lines.
  • Use high resolution pc3 configuration files, such as "DWG To PDF High Res.pc3"

Basically that's it. Although the conversion process is not complicated, the wrong setting may affect the viewing experience. Especially when sent to customers or partners, it is safe to test the export effect in advance.
